Nominal Voltage: 3.63 V Typical Capacity: 5300 mAh (5.3 Ah) Dimensions: 21.15 mm (D) × 70.00 mm (H) Weight: ~72 g
Charge Cut-off Voltage: 4.20 V Discharge Cut-off Voltage: 2.50 V Standard Charge Current: 5.3 A (1 C) Max Continuous Discharge Current: 10.6 A (2 C) Operating Temperature: • Charge – 0 °C to 50 °C • Discharge – -30 °C to 60 °C
Very High Capacity: Typical ~5,300 mAh, with a minimum rated capacity of ~5,140 mAh.
Nominal Voltage: ~3.63 V.
Long Cycle Life: Rated to retain ≥ 80% capacity after 1,000 cycles (at 1C charge / 1C discharge under specified conditions).
Moderate Discharge Capability: Max discharge current up to 3C (~15.9 A) per spec (not recommended continuously for cycle-life).
High Charge Current: Supports up to ~5,300 mA charging (though not for long-term cycle use).
Wide Operating Temperature Range: Charge 0°C to 45°C; Discharge –20°C to 60°C.
Low Internal Resistance: Initial AC resistance is very low (≈ 13 mΩ per vendor spec) helps with efficiency and heat management.
Robust Energy Density + Stability: Designed for applications needing high energy storage with reasonable current draw, such as e-bikes, energy storage systems, and high-capacity power packs.
